Hypetrain Vanover 2207.5 1860KV




The Motor That Wins Races

The Hypetrain Vanover Motor marks Hypetrain’s first race motor offering. Designed for absolute maximum racing performance, this motor is an exceptional choice for freestyle as well - taking a ton of abuse while still staying smooth.

Developed with the direct input of Drone Racing champion Alex Vanover, the Hypetrain Vanover clocks in at 1860 KV - perfect for 6S pilots looking for a superb competition motor. Alex has already proved the performance of these motors, by taking first place at the Osijek Drone Expo 2019 in Croatia, and obtaining Fastest Lap and Fastest Qualifying 3 Lap time at the MultiGP International Open World Cup.

With a state-of-the-art 2207.5 core, the Vanover motor has an incredible response time which allows you to fly precisely on the race track. It flies smooth, and has a very predictable throttle curve. The motor core is made with single strand, heat resistant copper windings. This optimized configuration allows advanced pilots to run a lower demag setting, which results in increased power output and efficiency with reduced risk of desync.

With these motors on your quad, you will not only have the fastest quad on the track, but also the best looking one. If you ask Alex, the navy blue bell cuts through the air faster than any other color!





WATCH THE VIDEO





ABOUT THE PILOT


Alex Vanover

Alex Vanover, who goes by the name “CaptainVanover” on the racetrack, is an extremely fast drone racing pilot. While most know Alex from his many race wins, he’s also an amazingly good freestyle pilot.

Some of Alex’s racing achievements include:

  • MultiGP 2017 Drone Nationals 1st place

  • Phoenix Cup 2018 & 2019 1st place

  • Chicago Cup 2018 1st place

  • XDC 2018 Team Race 1st place

  • Buffalo Bando 2018 1st place

  • FAI GwaCheon World Cup 2018 1st place

  • MultiGP Regional Series 1st place






TECHNICAL SPECIFICATIONS


Model: Hypetrain Vanover

  • Weight: 29.5 grams (without wires)

  • KV: 1860KV

  • Stator Diameter: 22 mm

  • Stator Height: 7.5 mm

  • Propeller Shaft Size: M5

  • Wires: 120 mm 20AWG Silicone Sheath

  • Bell Material: 7075-T6 Aluminum

  • Magnets: N52 Curved Magnets

  • Mounting Screw Pattern: 16×16 mm

  • Input Voltage: 4-6S

  • Bearings: ISC 4x9x4mm 940ZZ





PACKAGE CONTENTS

Each Hypetrain Vanover 2207.5 1860KV package contains:

  • 1x Hypetrain Vanover 2207.5 1860KV Motor

  • 1x M5 Nylock Propeller Nut

  • 5x M3 x 6mm Mounting Screws

  • 5x M3 x 7mm Mounting Screws

  • 1x Sticker





gALLERY
